PCB Capabilites

We know your printed circuit boards are as unique as you are. From your layer count to your surface finish, OnBoard Circuits, Inc. follows through with every detail of your design. We cover every phase of the production process from design to turn-key assembly, and can help you with your project at every step.

The OnBoard Promise

At OnBoard Circuits, Inc. our focus is quality, and that extends beyond your PCBs. We promise you top-notch customer service, communication, product management, and value. We work with companies large and small to ensure you have the high-quality product you deserve at the time and price that is right for you.

Printed Circuit Boards & PCB Services

OnBoard Circuits, Inc. is a full-service PCB supplier offering high-quality PCB services and accurate, quick PCB quotes. We strive to make the PCB purchasing process as simple as possible at every step of your product development. From quick-turn, high-tech PCB prototypes to full-scale PCB production, every phase, from design & layout to manufacturing, is monitored and managed by the highly qualified OnBoard team. OnBoard Circuits, Inc. works with your specs, budget, and PCB requirements to streamline your printed circuit board ordering process and provide you with the highest quality products at the best price available.

0 +
Project Completed
0 K
Customer Satisfaction

OnBoard Circuits, Inc. knows the importance of quality and reliability in today’s demanding marketplace. Our quality heritage and our commitment to customer satisfaction and excellence continually move us forward.

We look forward to working with you soon! Learn more about us by exploring our site or contacting us today.

Customer Satisfaction
99%
Problems Solving
96%

The OnBoard Difference

Knowledge & Experience

With over two decades in the printed circuit board industry, we’ve done it all. From military and aerospace to home appliances and university research projects, OnBoard Circuits, Inc. understands the breadth of the PCB industry and can help you perfect your PCB projects from design to functionality.

Domestic & Offshore Capabilities

So many factors go into your product design, OnBoard can help you decide what type of manufacturing fits your needs. With relationships built on decades of trust, both domestic and offshore, we can guarantee a quality, on-time product regardless of where you land.

On-Site Warehousing

Have you ever wished for a lower per-piece price and a quicker lead time? With our on-site warehouse we can have your repeat orders a day away without the quick-turn price tag.

Superior Customer Service

Our friendly, knowledgeable, OnBoard staff is here for you all day, everyday (yes, even on the weekends). Quick responses to emails, same day or next day PCB quotes, and answers to all of your technical, complicated, and weird questions. We’re here for you.

24/7 Availability

OnBoard Circuits, Inc. is available 24/7 for any of your circuit board needs. Our staff is here to answer any questions or concerns day, evening, night, and weekend!

Quick PCB Quotes

Our fast printed circuit board quote form is the easiest way to submit a quote request. If you have any schematics, artwork, CAD files, fab drawings or Gerber files you can upload them here. Not techy? Not a problem. Drag and drop your files here and we take care of the rest. A member of the OnBoard team will reach out to you within 24 hours.

Additional Information Suggested For PCB Quoting

  • Layers
  • Board Material
  • Finished Copper
  • Solder Mask
  • Board Thickness

The planes of copper connected by the plated through holes. Text on the board such as company name, logo or part number that reads correctly on the top layer will insure the layers are placed correctly. All orders placed as "1 layer" will be treated as single sided and the hole barrels will be non-plated.

FR4 - Glass laminates are widely used for subtractive Printed Circuit Board fabrication because of their ability to meet a wide variety of processing conditions. Thermally stable copper-clad epoxy-glass laminates offer high mechanical strength and machinability and outstanding electrical characteristics. Designed for single and double-sided boards, they provide a combination of processing flexibility and finished board performance needed for many SMT applications.

HiTg FR4 - A high Tg is very important for the PCBs to guard against barrel cracking and pad fracture during the soldering process.

Rogers - Used when advanced electrical properties are needed, Rogers material can meet design requirements at 500MHz and above. Capable of extremely low dielectric loss. Learn more at the Rogers Tech Support Hub.

Polyimide - This material uses special resins that provide improvement in mechanical properties. The material is especially good for high frequency performance.

This is how much copper your board will have on its surface. It is the copper foil thickness, plus plated copper, minus surface preparation. It is given in oz / per sq foot. 1 oz = a minimum of 0.0012"- 0.0014" thickness. We offer finished copper of 1oz. up to 10oz. If you need a different finished copper amount, please note your needs in the additional comments section of the request.

This is typically green but we also offer a variety of colors. We also call it LPI, for Liquid Photo-Imagable solder mask, which is the type we use. It keeps the traces from shorting together when the soldering is done. When no soldermask is requested, we coat the areas of the board not covered with optional solder mask with solder. This is a mix of Tin and Lead.

Standard base thickness is 0.062". Based on customer needs we can produce flex boards as thin as 0.0059" and boards as thick as 0.4".
